RISE ONE Receives the Shizuoka City SME Technology Award
RISE ONE Receives the Shizuoka City SME Technology Award
jpriseone
Sep 30


Automatic Semiconductor Wafer Transfer Mechanism
【Machine Name】 Automatic Semiconductor Wafer Transfer Mechanism 【Overview】 A system that automatically supplies semiconductor wafers to an inspection machine. It takes wafers out of the carrier, corrects their position through pre-alignment, and feeds them to the inspection unit. After inspection, wafers are automatically unloaded and returned to their original positions in the carrier. A vibration isolation mechanism prevents vibration during inspection. 【Specifications & Fe
jpriseone
Sep 30


Automatic Feeder for Ultrasonic Inspection Machines
【Machine Name】 Automatic Feeder for Ultrasonic Inspection Machines 【Overview】 A system that transfers cases loaded with inspection items, feeds them into an ultrasonic flaw detection unit, and carries the cases out after data collection and report output. ◇ Automatically transfers cases loaded with products. ◇ Reads lot information from QR codes, feeds products into the ultrasonic flaw detector, and inputs/outputs image analysis data. ◇ After inspection, blows off moisture wi
jpriseone
Sep 30


PETRA Nanoimprint Stepper
【Machine Name】 Nanoimprint Stepper 【Overview】 A system built by RISE ONE under the supervision of AIST (Tsukuba). It transfers the pattern of a finely engraved mold in a single step. A key feature of this system is its ability to keep the residual layer thin after transfer. 【Specifications & Features】 - Mechanisms & Functions - ■ Nanoimprint unit [mold table] with α/β mold adjustment mechanism ■ High-precision XYθ wafer stage ■ Wafer bending mechanism and XY stage ■ Alignment
jpriseone
Sep 30


Imprint System
A system built by RISE ONE under the supervision of AIST (Tsukuba) and the Minimal Fab Development Association. 【Machine Name】 Imprint System 【Overview】 A system built by RISE ONE under the supervision of AIST (Tsukuba) and the Minimal Fab Development Association. 【Specifications & Features】 ■ Target workpiece material: Silicon, GaAs ■ Size: Min. φ12.5 mm, Max. φ100 mm ■ Fixing method: Mechanical clamping with holding parts ■ Replica mold material: PDMS / thermoplastic resin
jpriseone
Sep 30


Minimal Mask Aligner
A system built by RISE ONE under the supervision of AIST (Tsukuba) and the Minimal Fab Development Association. 【Machine Name】 Minimal Mask Aligner 【Overview】 A system built by RISE ONE under the supervision of AIST (Tsukuba) and the Minimal Fab Development Association. 【Specifications & Features】 ■ 5-megapixel camera optics for front and back alignment marks ■ 2-megapixel camera optics for orientation flat detection ■ XYZ alignment axis resolution: 0.1 µm ■ θ-axis resolution
jpriseone
Sep 30


Roller-Press Imprint System
A system for UV imprinting from large-area molds onto glass substrates. 【Machine Name】 Roller-Press Imprint System 【Overview】 A system for UV imprinting from large-area molds onto glass substrates. 【Specifications & Features】 ■ Automatic inkjet application of UV resin ■ Roller-press method using a transfer roller; transfer speed 0.1–50.0 mm/s ■ Grade 00 granite surface plate for flatness, 500 × 500 mm ■ Compatible mold size: 450 × 450 mm ■ UV light source (LED): 375 nm wavele
jpriseone
Sep 30


IC Height Inspection System Type 2
A system that measures the height of ICs in automatically loaded JEDEC trays. NG units are automatically ejected after measurement. 【Machine Name】 IC Height Inspection System Type 2 【Overview】 A system that measures the height of ICs stored in automatically loaded JEDEC trays. NG units are automatically ejected after measurement. 【Specifications & Features】 ■ Equipped with two KEYENCE WI-010 3D displacement sensors ■ Measurement time: 0.35 s per tray ■ Tray changeover within
jpriseone
Sep 30


IC Height Inspection System Type 1
A system that measures the height of ICs in lead frames loaded automatically or manually. 【Machine Name】 IC Height Inspection System Type 1 【Overview】 A system that measures the height of ICs in lead frames loaded automatically or manually. 【Specifications & Features】 ■ Measures within a 10 mm field of view and up to 0.7 mm in height ■ Up to 99 registered recipes ■ X/Y-axis minimum movement resolution: 1 µm ■ Max stroke: X-axis 300 mm, Y-axis 100 mm
jpriseone
Sep 30


ECU Function Inspection System
Supports a wide range of models by combining a general-purpose I/O box with dedicated jigs. Can also run standalone through PLC integration. Overview An inline inspection system that supports ECU inspection for various models by combining a general-purpose I/O box with dedicated jigs. It handles ECU inspection and programming via LIN, CAN, CAN FD, and CXPI communication, and can also run standalone through PLC integration. Specifications & Features Continuous processing with
jpriseone
Sep 30


ECU Final Inspection System
A large inline inspection system. Enables fully automated production lines. Specifications & Features ECU package inspection Communication testing via LIN and CAN Simultaneous inspection of multiple units Automatic OK/NG sorting Automatic ejection of NG workpieces Workpiece verification by QR code Traceability system
jpriseone
Sep 30


Swivel Final Inspection System
An inspection system for swivel functions. Performs rotation inspections for the swivel mechanism. Specifications & Features ・Current inspection ・No-load rotation accuracy inspection ・Loaded rotation accuracy inspection ・Error-proofing (poka-yoke) check
jpriseone
Sep 27


Lamp Final Inspection System
An inspection system for automotive lamp functions. Performs shaft extension/retraction and abnormal noise inspections. Specifications & Features ・Current inspection ・No-load shaft accuracy inspection ・Loaded shaft accuracy inspection ・Abnormal noise inspection ・Error-proofing (poka-yoke) check
jpriseone
Sep 27


Line Checker
An inspection machine for checking the operation of home appliances.
jpriseone
Sep 27


DX: Equipment Data Utilization
↓ Download the materials here (Japanese)
